Scree plot for PCA results — spec_pca

Creates a customizable scree plot based on a `prcomp` object showing variance explained by each component.

Usage

spec_pca_screeplot(
  pca,
  n = 10,
  show_labels = TRUE,
  show_cumulative = TRUE,
  bar_color = "steelblue",
  line_color = "darkred",
  show_kaiser = FALSE,
  title = "Scree Plot",
  subtitle = NULL,
  accuracy = 1
)

Arguments

pca: A PCA object returned by [prcomp()].
n: Number of components to display. Defaults to 10.
show_labels: Logical. Show percentage labels on bars? Default is TRUE.
show_cumulative: Logical. Show cumulative variance line? Default is TRUE.
bar_color: Fill color for bars. Default is "steelblue".
line_color: Color of the cumulative line and points. Default is "darkred".
show_kaiser: Logical. Show Kaiser criterion line? Default is FALSE.
title: Plot title. Default is "Scree Plot".
subtitle: Optional plot subtitle.
accuracy: Number of decimal places for variance percentages. Default is 1.

Value

A ggplot2 scree plot object.

Examples

pca <- prcomp(USArrests, scale. = TRUE)
spec_pca_screeplot(pca, n = 4)

spec_pca_screeplot(pca, show_kaiser = TRUE, bar_color = "darkblue")
